International HV™ SERIES
MAKE & MODEL
Manufacturer:
Model:
DETAILED SPECIFICATIONS
| Series/Category: | SEVERE DUTY |
| Axle Configurations: | 4x2, 4x4, 6x4, 6x6, 8x6 Tridem |
| Cab/Sleeper Configurations: | Day Cab, Extended Cab, Crew Cab (no sleepers) |
| Wheelbase Range: | 136 - 340" |
| Exhaust Systems: | Single canister after-treatment device, Frame Mounted Right Side, Back, or Under Cab Short Horizontal Tailpipe Single Vertical Tailpipe, Right Side Back of Cab |
| Front Axles: | Dana Spicer: Non-Driving: 10,000 - 22,000 lbs. Fabco: Driving: 10,000 - 22,000 lbs. Meritor: Non Driving: 10,000 - 22,000 lbs.; Driving: 10,000 - 18,000 lbs. |
| Rear Axles: | Single Rear Axle (4x2) : Meritor : Single Reduction: 17,000 - 30,000 lbs., Double Reduction: 26,000 - 38,000 lbs*, Two-Speed: 21,000 - 23,000 lbs., Dana : Single Reduction: 17,500 - 31,000 lbs., Two-Speed: 19,000 - 23,000 lbs., Tandem Rear Axle (6x4) : Meritor: Single Reduction: 34,000 - 52,000 lbs., Dana: Single Reduction: 46,000 lbs. |
| Transmissions: | Manual: Eaton: 6, 8LL (10), 9ALL (11), 13, 15, 18 speed *, Automated Manual: Eaton UltraShift PLUS: 10, 11, 13, 18 speed, Eaton Fuller Advantage: 10 speed, Automatic: Allison Automatic: EVS, RDS, HS series * (HVMRD 6, 10, 11, and 13 only) |
| Fuel Tanks: | 40 - 120 Gallons, Single or Dual, Non-Polished or Polished Aluminum, Mounted Right or Left Side Under Cab |
| Power Steering: | Single Gear Power, Dual Gear Power on Front Axle 16,000 lbs. And Above |
| GVW: | 51,000 - 73,000 lbs. |
| Cab Interior Trim Levels: | Classic, Diamond |
| Models: | 107" BBC Set-Back Front Axle, 107" BBC Set-Forward Front Axle, 113" BBC Set-Back Front Axle, 113" BBC Set-Forward Front Axle |
| Engines: | Cummins® B6.7: 200 hp, 520 lb.-ft. torque, up to 325 hp, 750 lb.-ft. torque, International® A26 |
| Frame Rails: | Heat Treated Alloy Steel 120,000 PSI 11.25" x .5" thick Super Single Rail |
| Front Suspensions: | Spring Multileaf: 14,000 - 20,000 lbs. Parabolic Taperleaf: 8,000- 23,000 lbs. |
| Rear Suspensions: | Chalmers: 23,000 - 52,000 lbs., Hendrickson: RT: 34,000 - 52,000 lbs., HAS: 23,000* - 46,000 lbs. HMX: 40,000 - 46,000 lbs. Primaax: 20,000 - 46,000 lbs., 69,000 lbs. (Tridem), Link: 46,000 lbs., International: 20,000 - 40,000* lbs. |
| Brakes: | Air Disc Brakes with ABS, Optional Traction Control, Optional Electronic Stability Program with Traction, Air Disc Brakes |
| Headlights: | Halogen |
| Tires: | Continental, Michelin, Goodyear, Bridgestone |
DESCRIPTION
HV507
The new HV507 from International® has the uptime, productivity and safety needed to deliver on the most demanding jobs. Its standard wide-track front axle provides excellent maneuverability, and its compact 107″ BBC and set-forward axle configuration is ideal for weight-sensitive bridge formula applications. The HV507 features a new, roomier interior with a powerful new HVAC system and new controls that help keep drivers comfortable and productive over long hours on the job. The advanced and dependable Diamond Logic® Electrical System offers custom, user-programmable interlocks to enhance operator safety. Whether you’re restoring power following a major storm, clearing the way after a heavy snowfall or performing other key roadwork, the HV507 is a hard-working addition to your fleet.
Applications:
Municipal plow
Construction dump
Bridge formula applications
4X4 Fire and emergency
HV607
Uptime is upfront in every aspect of the new International® HV607. It boasts a 0.5″ super single frame rail that’s stronger, lighter and more corrosion-resistant than reinforced rails. It features a double-sided galvanized steel cab and a new, roomier interior that’s designed to optimize your crew’s comfort and productivity. They’ll operate with optimal safety thanks to an industry-leading Diamond Logic® Electrical System that now includes up to 30 easy-to-operate programmable switches. Drivers will also appreciate enhanced visibility and a more maneuverable 107″BBC with a wide-track, set-back front axle.
Applications:
Construction dump
Refuse
Platform stake/crane
Wrecker
HV513
Everything about the new HV513 is designed to optimize your uptime. It’s powered by a new International® A26™ engine that’s built from the block up to redefine efficiency, performance and durability. It includes the easily programmable, time-saving capabilities of Diamond Logic®, the industry’s most advanced electrical system. The HV513 also features a roomier interior with a best-in-class new HVAC system to keep both driver and crew focused, comfortable and productive for long hours on the job. The HV513 features a 113″ BBC with a wide-track, set-forward front axle providing the flexibility to deliver for your fleet in hundreds of applications.
Applications:
Concrete Mixer
Crane
Roll-off
Heavy Construction Dump
HV613
International® trucks have always answered the call for the toughest jobs around. Now there’s a new breed of vocational truck that redefines the standard for uptime and productivity. Introducing the new International HV™ Series. The HV613 offers the superior maneuverability of a set-back, wide-track front axle. It also includes the industry standard for operator safety, versatility and dependability in its Diamond Logic® Electrical System. Plus, the HV613 reaches new levels of uptime, efficiency and performance with its advanced new A26™ engine and new interior that includes new, driver-focused controls and a new class-leading HVAC system.
Applications:
Refuse
Heavy Construction Dump
Recovery
Concrete Mixer
